PT1000 Thermal Resistance Linear Conversion Temperature Transmitter Module

PT1000 Thermal Resistance Linear Conversion Temperature Transmitter Module

Q-BAIHE

PT1000 Thermal Resistance Linear Conversion Temperature Transmitter Module\n \n \n \n \nFeature:\n \nPT1000 turn voltage module \n \nThis is a linear conversion module that converts the input thermal resistance signal to a temperature (voltage signal) output via an internal chip process.\n \nThere are two output voltage range options.\n \n \nModule parameters\n \n1, working voltage: 9V ~ 24V\n \n2, input resistance: Pt1000 thermal resistance\n \n3, output voltage: 0.00V ~ 5.00V / 0.00V ~ 10.00V\n \n4, temperature range: -50 ~ +300 (degrees).\n \n5, output: the circuit board S2 pad: open (output 0.00V ~ 5.00V); shorted (output 0.00V ~ 10.00V), the\n \ndefault is open.\n6, application: remote data acquisition and control equipment;\n \n7, size: (length) 26mm * (width) 23mm * (height) 10mm\n \n8, the module interface:\n \n24V: positive power connector (9V ~ 24V).\n \nG: power to the Ground.\n&:

Compare prices (1 shop)

Sort: Price: lowest first Price: highest first
shop Price Action
16,18 GBP Go to shop
