Whadda Usb Experiment Interface Board Kit

Name: Whadda Usb Experiment Interface Board Kit
Brand: WHADDA

WHADDA

The K8055N interface board has 5 digital input channels and 8 digital output channels. There are also two analogue inputs and outputs with 8-bit resolution. The number of inputs/outputs can be further expanded by connecting up to 4 more cards to the PC’ 5 Digital inputs (0=ground, 1=open) (on board test buttons provided) 2 Analogue inputs with attenuation and amplification option (internal test +5V provided) 8 Digital open collector output switches (50V/100mA max.) (on board LED indication) 2 Analogue outputs 0-5V, Output resistance 1K5 PWM 0-100% open collector outputs max. 100mA/40V (on board LED indication) General conversion time: 20ms per command Power supply through USB: 70mA approx Diagnostic software with DLL included Dimensions (WxHxD): 145x20x88mm
