Peak Atlas Component Analyser

Name: Peak Atlas Component Analyser
Brand: Peak Electronic Design

Peak Electronic Design

--\nOur eBay Store\n\nPeak DCA55 Atlas Component Analyser\n\nProduct Details\n\nA smart and really clever instrument that will automatically analyse almost any semiconductor. Just connect it any way round and press test. It will automatically identify the type of part you have, identify the pinout and measure important parameters.\n\nIt supports most bipolar transistors, Darlingtons, MOSFETs, diodes, LEDs and more. For 2-leaded components, just use any pair of test clips, any way round. It will even identify special component features such as fly-wheel diodes and resistor shunts on transistors.\n\nThe Atlas DCA will measure current gain for transistors, gate threshold for MOSFETs and voltage drops for semiconductor junctions (such as transistor base-emitter junctions, diodes, LEDs etc). \n\n--Automatic identification of most discrete semiconductor components\n--Supports Bipolar Transistors, MOSFETs, JFETs, Diodes, LEDs, Diode Networks (such as SOT23 networks) and more\n--Connect any ;
