SCHNEIDER LRD3355 Thermal relay

SCHNEIDER ELECTRIC

Schneider Electric LRD3355 Thermal Overload Relay 1NO + 1NC 40A rating 3P TeSys\n\nVAT invoice will be provided.\n\nSpecificationsMainRangeTeSysProduct nameTeSys LRD\nTeSys DecaProduct or component typeDifferential thermal overload relayDevice short nameLRDrelay applicationMotor protectionProduct compatibilityLC1D80\nLC1D95Network typeDC\nACThermal overload classClass 10A conforming to IEC 60947-4-1Thermal protection adjustment range30\u202640 A[Ui] rated insulation voltagePower circuit: 1000 V conforming to IEC 60947-4-1\nPower circuit: 600 V conforming to CSA\nPower circuit: 600 V conforming to ULComplementaryNetwork frequency0...400 HzMounting supportPlate, with specific accessories\nRail, with specific accessories\nUnder contactorTripping threshold1.14 +/- 0.06 Ir conforming to IEC 60947-4-1Auxiliary contact composition1 NO + 1 NC[Ith] conventional free air thermal current5 A for signalling circuitPermissible current0.72 A at 500 V AC-15 for signalling circuit\n0.06 A at 440 V DC*
